General Feature
Application Client PCs, PlayStation5
FORM FACTOR M.2 (2280)
INTERFACE PCIe 5.0 x4, NVMe 2.0
DIMENSION (WxHxD) 80.15 x 22.15 x 2.38 mm
WEIGHT Max 9.0g Weig
STORAGE MEMORY Samsung V-NAND TLC
CONTROLLER Samsung in-house Controller
CACHE MEMORY Samsung 4GB Low Power DDR4X SDRAM
Special Feature
TRIM Support Supported
S.M.A.R.T Support Supported
GC (GARBAGE COLLECTION) Auto Garbage Collection Algorithm
ENCRYPTION SUPPORT
AES 256-bit Encryption (Class 0) TCG/Opal IEEE1667 (Encrypted drive)
WWN SUPPORT Not supported
DEVICE SLEEP MODE SUPPORT Yes
Performance
SEQUENTIAL READ Up to 14,800 MB/s
SEQUENTIAL WRITE Up to 13,400 MB/s
RANDOM READ (4KB, QD32) Up to 2,200,000 IOPS
RANDOM WRITE (4KB, QD32) Up to 2,600,000 IOPS
Environment
AVERAGE POWER CONSUMPTION (System Level) Average 9 W Maximum 8.2 W (Burst mode)
POWER CONSUMPTION (IDLE)3) Max. 6.5 mW
POWER CONSUMPTION (DEVICE SLEEP) Max. 5.7 mW
ALLOWABLE VOLTAGE 3.3 V ± 5 % Allowable voltage
RELIABILITY (MTBF) 1.5 Million Hours Reliability (MTBF)
OPERATING TEMPERATURE 0 – 70 ℃ Operating Temperature
Shock 1,500 G & 0.5 ms (Half sine)
Accessories
INSTALLATION KIT Not Available
Software
MANAGEMENT SW Magician Software for SSD management
Warranty 5-year or 2400 TBW limited warranty
