Dimensions 100 mm x 69.85 mm x 6.8 mm (3.94″ x 2.75″ x 0.28″)
Weight 45 g (1.59 oz)
Flash Type 3D NAND flash
Capacity 120 GB/240 GB/480 GB/960 GB
Operating Temperature 0°C (32°F) ~ 70°C (158°F)
Operating Voltage 5V±5%
Sequential Read/Write (CrystalDiskMark)
960 GBup to 550/500 MB/s 480 GBup to 530/480 MB/s 240 GBup to 500/330 MB/s 120 GBup to 500/300 MB/s
4K Random Read/Write (IOmeter)
960 GBup to 65,000/75,000 IOPS 480 GBup to 50,000/75,000 IOPS 240 GBup to 40,000/75,000 IOPS 120 GBup to 28,000/75,000 IOPS
Terabytes Written (TBW)
960 GB320 TBW 480 GB160 TBW 240 GB80 TBW 120 GB40 TBW
Mean Time Between Failures (MTBF) 2,000,000 hour(s)
Drive Writes Per Day (DWPD) 0.3 (3 yrs)
Note
Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
For Mac users please visit our Apple Solutions here.
Package Contents Full unit
Operating System
Microsoft Windows 7
Microsoft Windows 8
Microsoft Windows 10
Linux Kernel 2.6.31 or later
Technology
TRIM & NCQ Command
S.M.A.R.T.
DDR3 DRAM Cache –
Advanced Garbage Collection
DevSleep Mode
RAID Engine
LDPC Coding
