CPU:
AMD AM4 Socket for AMD Ryzen 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics Processors
Memory:
4 x DIMM, Max. 128GB, DDR4 4400(O.C)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory
3rd/2nd/1st Gen AMD Ryzen/ 2nd and 1st Gen AMD Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics Processors
Dual Channel Memory Architecture
Graphic:
1 x HDMI 2.0b
1 x DisplayPort 1.2
*Graphics specifications may vary between CPU types.
Integrated Graphics Processor
Expansion Slots:
2 x PCIe 3.0 x16 (x16 or x8/x4)
1 x PCIe 2.0 x16 (x4 mode) *
3rd/2nd/1st Gen AMD Ryzen Processors
1 x PCIe 3.0 x16 (x4 mode)
AMD B450 chipset
3 x PCIe 2.0 x1
1 x PCIe 3.0 x16 (x8 mode)
AMD Athlon with Radeon Vega Graphics Processors
USB Ports:
4 x USB 3.2 Gen 1 port(s)(3 x Type-A +1 x USB Type-C)
Front USB Port ( Total 4 )
2 x USB 3.2 Gen 2 port(s)(2 x Type-A)
Rear USB Port ( Total 8 )
2 x USB 3.2 Gen 1 port(s)
2 x USB 2.0 port(s)
Form Factor:
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
