Dimensions : 80.0 mm x 22.0 mm x 3.58 mm (3.15″ x 0.87″ x 0.14″)
Weight : 9 g (0.32 oz)
M.2 Type
2280-D2-B-M (Double-sided)
Bus Interface : SATA III 6Gb/s
Storage
Flash Type : 3D NAND flash
Capacity : 128 GB/256 GB/512 GB/1 TB/2 TB
Operating Temperature 0°C (32°F) ~ 70°C (158°F)
Operating Voltage : 3.3V±5%
Performance
Sequential Read/Write (CrystalDiskMark)
2 TBup to 560/520 MB/s 1 TBup to 560/500 MB/s 512 GBup to 560/500 MB/s 256 GBup to 530/400 MB/s 128 GBup to 560/380 MB/s
4K Random Read/Write (IOmeter)
2 TBup to 90,000/85,000 IOPS 1 TBup to 85,000/85,000 IOPS 512 GBup to 80,000/85,000 IOPS 256 GBup to 45,000/70,000 IOPS 128 GBup to 55,000/65,000 IOPS
Terabytes Written (TBW)
2 TB1,120 TBW 1 TB560 TBW 512 GB280 TBW 256 GB140 TBW 128 GB70 TBW
Mean Time Between Failures (MTBF) 2,000,000 hour(s)
Drive Writes Per Day (DWPD) 0.3 (5 yrs)
Note
Speed may vary due to host hardware, software, usage, and storage capacity.
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
Operating System
Microsoft Windows 7
Microsoft Windows 8
Microsoft Windows 10
Linux Kernel 2.6.31 or later
Note
Please make sure that your computer has a M.2 slot.
Technology
TRIM & NCQ Command
S.M.A.R.T.
DDR3 DRAM Cache
Advanced Garbage Collection
DevSleep Mode –
RAID Engine
LDPC Coding
