SPECIFICATION
P/N :
PS-TPD-0750FNFAGE-4 (750W)
PS-TPD-0850FNFAGE-4 (850W)
PS-TPD-1000FNFAGE-4 (1000W)
PS-TPD-1650FNFAGE-4 (1650W)
WATTS : 750W / 850W / 1000W / 1650W
MODEL :
TPD-0750AH3FCG (750W)
TPD-0850AH3FCG (850W)
TPD-01000AH3FCG (1000W)
TPD-01650AH3FCG (1650W)
MAX. OUTPUT CAPACITY :
750W (untuk 750W)
850W (untuk 850W)
1000W (untuk 1000W)
1650W (untuk 1650W)
COLOR : Black
DIMENSION ( W / H / D ) : 150mm(W) x 86mm(H) x 160mm(D)
WEIGHT : 1.63 KG
PFC (POWER FACTOR CORRECTION) : Active PFC
POWER GOOD SIGNAL : 100-150 msec
HOLD UP TIME : > 17msec at 100% of full load
INPUT CURRENT : 10.0A / 5.0A
INPUT FREQUENCY RANGE : 50/60Hz
INPUT VOLTAGE : 100V – 240V~
OPERATING TEMPERATURE : 0°C to + 40°C
OPERATING HUMIDITY : 20% to 90%,non-condensing
STORAGE TEMPERATURE : -20°C to + 70°C
STORAGE HUMIDITY : 5% to 95%, non-condensing
COOLING SYSTEM : 13.5cm fluid bearing fan
EFFICIENCY : Meet 80 PLUS®Gold at 115Vac input.
MTBF : 100,000 hrs minimum
SAFETY APPROVAL : CE/UKCA/cTUVus/TÜV/FCC/IC/BSMI/EAC/CB/CCC
PCI-E CONNECTOR :
PCIe 6+2Pin X 4
PCIe 12+4Pin X 1
PROTECTION : OCP, OVP, UVP, OPP, SCP, OTP
