CPU
– AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors*
* Refer to www.asus.com for CPU support list.
Chipset
– AMD B650
Memory
– 4 x DIMM, Max. 128GB, DDR5
– 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 ECC & Non-ECC, Un-buffered Memory*
– Dual Channel Memory Architecture
– Supports AMD EXTended Profiles for Overclocking (EXPO™)
– OptiMem II
Graphics
– 1 x DisplayPort*
– 1 x HDMI® port**
* Supports max. 8K@60Hz as specified in DisplayPort 1.4.
** Supports 4K@60Hz as specified in HDMI 2.1.
*** VGA resolution support depends on processors’ or graphic cards’ resolution.
Expansion Slots
– AMD Ryzen™ 7000 Series Desktop Processors*
— 1 x PCIe 4.0/3.0 x16 slot
– AMD B650 Chipset
— 1 x PCIe 4.0/3.0 x16 slot (supports x4 mode)
— 1 x PCIe 4.0/3.0 x1 slot
* Please check PCIe bifurcation table in support site (https://www.asus.com/support/FAQ/1037507/).
Storage
– Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports*
– AMD Ryzen™ 7000 Series Desktop Processors
— M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
— M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
– AMD B650 Chipset
— 4 x SATA 6Gb/s ports
*AMD RAIDXpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10.
Ethernet
– 1 x Realtek 2.5Gb Ethernet
– TUF LANGuard
Wireless & Bluetooth
– Wi-Fi 6
– 2×2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax)
– Supports 2.4/5GHz frequency band
– Bluetooth v5.2
Form Factor
– micro-ATX Form Factor
– 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)
