P/N
CA-1M3-00M1WN-00
SERIES
H Series
MODEL
H200 TG RGB
CASE TYPE
Middle tower
DIMENSION (H X W X D)
454 x 210 x 416mm
(17.9 x 8.3 x 16.4 inch)
NET WEIGHT
7.4 kg / 16.31 lbs
SIDE PANEL
4mm Tempered Glass x1 (Left)
COLOR
Exterior & Interior : Black
MATERIAL
SPCC
COOLING SYSTEM
Rear (exhaust) :
120 x 120 x 25 mm fan
(1000rpm, 16dBA)
DRIVE BAYS
-ACCESSIBLE
-HIDDEN
–
2 x 3.5’’ or 3 x 2.5’’
EXPANSION SLOTS
7
MOTHERBOARDS
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
I/O PORT
USB 3.0 x 2, HD Audio x 1, RGB Button x 1
PSU
Standard PS2 PSU (optional)
FAN SUPPORT
Front:
3 x 120mm , 2 x 140mm
Top:
2 x 120mm , 2x 140mm
Rear:
1 x 120mm , 1 x 140mm
RADIATOR SUPPORT
Front:
1 x 240mm , 1 x 280mm
Top:
1 x 240mm
CLEARANCE
CPU cooler height limitation: 180mm
VGA length limitation: 320mm
